Surly Grappler MTB Frameset 27.5"/29"
The Grappler frameset is built for singletrack sessions, all-day dirt rides, drop-bar trail biking, and bikepacking adventures.
Colors:
- Subterranean Homesick Blue (2024)
- Purple Dust Bunny (2025)
Weight:
- Size M: Frame ≈ 3.1 kg / Fork ≈ 1.45 kg
Features:
Frame:
- Drop-bar trail bike frame made from 100% Surly 4130 Chromoly steel
- Natch Tubing
- Main frame double-butted
- Gusset reinforcements on top and down tube
- TIG welded
- Electro-coat for rust protection
- Non-suspension-corrected
- Rear spacing: 12 x 148 mm AND 12 x 142 mm
- Gnot-Boost horizontal dropouts with derailleur hanger, compatible with 142 mm hubs (allows 2 mm flex per side to accommodate hub width)
- Custom rear design compatible with single-speed or internal-gear hubs
- Mounts for fenders and racks
- Three-pack mounts on upper and lower down tube; seat tube bottle mounts for sizes S–XL
Fork:
- 1/8" fork made from 100% Surly 4130 Chromoly steel
- Hub spacing: 15 x 110 mm
- Disc brake compatible
- Double-butted
- TIG welded
- Electro-coat for rust protection
- Mounts for fenders and racks
- Three-pack mounts on each fork blade
Clearances & Specs:
- Seatpost diameter: 30.9 mm (Stealth dropper compatible)
- Headset: EC34/28.6 – EC34/30 OR ZS34/28.6 – EC34/30
- Front derailleur clamp: 34.9 mm, top pull
- Bottom bracket: 73 mm BSA
- Brakes: Disc – 51 mm I.S. (max. 203 mm rotor)
Tire clearance:
- Frame: 27.5 x 3" (27.5 x 2.8" with fender), 29 x 2.1–2.5" with or without fender
- Fork: 27.5 x 2.8" (27.5 x 2.6" with fender), 29 x 2.2" (29 x 2.0" with fender)
Max Chainring:
- 1x (MTN): 36T
- 2x (MTN): 36/26T
- 1x (Boost): 38T
- 2x (Boost): 39/32T
Sizes & Colors:
- Purple Dust Bunny - XS | FM0536
- Purple Dust Bunny - S | FM0537
- Purple Dust Bunny - M | FM0538
- Purple Dust Bunny - L | FM0539
- Purple Dust Bunny - XL | FM0540
- Subterranean Homesick Blue - XS | FM2694
- Subterranean Homesick Blue - S | FM2695
- Subterranean Homesick Blue - M | FM2696
- Subterranean Homesick Blue - L | FM2697
- Subterranean Homesick Blue - XL | FM2698
Included:
- 1 x Surly Grappler Frame
- 1 x Surly Grappler Fork
- 1 x Surly Seatpost Clamp 33.1 mm
- 1 x Rear Thru-Axle
- 1 x Front Thru-Axle
